Accepting an in-kind grant for the Ministry of Agriculture

بعبدا في ٣٠ أيلول ٢٠٢٥

الإمضاء: جوزاف عون

صدر عن رئيس الجمهورية

رئيس مجلس الوزراء

الإمضاء: نواف سلام

وزير الزراعة

الإمضاء: نزار هاني

وزير المالية

الإمضاء: ياسين جابر

Part C- Spare Parts

Item | Name of the machine | Spare parts Description | Qty

1 | Gas Chromatography 7890, Agilent | Liner,UI,universal,low prss drop,GW,5/pk | 5

2 | Gas Chromatography 7890, Agilent | Filament, high / Filament,high temperature EI for GCMS | 3

3 | Gas Chromatography 7890, Agilent | Column nut, universal 2/PK | 3

4 | Gas Chromatography 7890, Agilent | Column Nut for MS interface / Interface | 5

5 - | Gas Chromatography 7890, Agilent | Syringe, 10ul FN 23-26s/42/HP | 10

6 | Gas Chromatography 7890, Agilent | Ferrule, 0.4mm VG 0.1-0.25 col 10/PK | 3

7 | High-performance liquid chromatography 1260, , Agilent | Stator face assy for 0101-0921 valva / valve | 3

8 | High-performance liquid chromatography 1260, , Agilent | Isolation seal for 0101-0920/1 valves | 3

9 | High-performance liquid chromatography 1260, , Agilent | Rotor seal (Vespel, 400 bar, 2 grooves) | 3

10 | High-performance liquid chromatography 1260, , Agilent | Rotor seal (Vespel, 400 bar, 3 grooves) | 3

11 | High-performance liquid chromatography 1260, , Agilent | Rotor Seal 2ps/6pt RC IV, P: A/B | 3

12 | High-performance liquid chromatography 1260, , Agilent | PTFE Frits 5PK | 8

13 | High-performance liquid chromatography 1260 . Agilent | Loop ST 0.5 100µL SI/SI | 4

14 | High-performance liquid chromatography 1260, , Agilent | Capillary Steel 380mm x 0.17mm S/S | 6

15 | High-performance liquid chromatography 1260, , Agilent | PE-Pump Seal 2/PK | 5

16 | High-performance liquid chromatography 1260, , Agilent | Seal Pump | 8

17 | High-performance liquid chromatography 1290, , Agilent | Metering device Seal PE 1290 LC Sampler | 1

18 | High-performance liquid chromatography 1290, , Agilent | Bearing Ring | 1

19 | High-performance liquid chromatography 1260, , Agilent | Flash lamp for G1321A fluorescence det | 1

20 | High-performance liquid chromatography 1260 . Agilent | Deuterium lamp w. RFID for DAD/MWD | 6

21 | High-performance liquid chromatography 1260 . Agilent | Glass filter, solvent inlet | 15

22 | High-performance liquid chromatography 1260 . Agilent | u-Vacuum Degasser tubing kit | 1

23 | High-performance liquid chromatography 1260 . Agilent | Solvent tubing, 5m, 1.5mm id, 3mm od | 2

24 | High-performance liquid chromatography 1260, , Agilent | Frit adapter, 3mm 4/PK | 2

25 | High-performance liquid chromatography 1260, , Agilent | VALVE-CARTRIDGE | 4

26 | High-performance liquid chromatography 1260, , Agilent | Sieves (SS) for Outlet Valve 10/PK | 2

27 | High-performance liquid chromatography 1260, , Agilent | Sapphire Piston | 4

28 | High-performance liquid chromatography 1290, , Agilent | Capillary ST 0.12x220 S/S | 1

29 | High-performance liquid chromatography 1290, , Agilent | Sapphire Piston 1220/1260/1290 | 2

30 | High-performance liquid chromatography 1260, , Agilent | Seal Cap Assembly | 4

31 | High-performance liquid chromatography 1290, , Agilent | Piston 1290 Infinity pump, ceramic | 2

32 | High-performance liquid chromatography 1290, , Agilent | 2-pos/6-port, Rotor seal | 2

33 | High-performance liquid chromatography 1260, , Agilent | Deuterium lamp 8-pin w. RFID for DAD | 2

34 | Gas Chromatography 7890. Agilent | HEAT SINK COMPOUND SYNTH/REFRC | 1

35 | High-performance liquid chromatography 1260, , Agilent | Tungsten Lamp assembly, G1315A, 8453 | 4

36 | High-performance liquid chromatography 1260, , Agilent | Flushing / Pluming KIT for 4 Channel Vacuum Deg | 1

37 | High-performance liquid chromatography 1260 . Agilent | Capillary, damper to inlet chamber 2 | 1

38 | High-performance liquid chromatography 1260, , Agilent | Capillary, outlet valve to damper | 1

39 | High-performance liquid chromatography 1260, , Agilent | Active inlet valve,without cartridge | 4

40 | High-performance liquid chromatography 1260, , Agilent | Passive Inlet Valve 1220/1260 | 2

41 | High-performance liquid chromatography 1260, , Agilent | Outlet Ball Valve for 1100/1200/1260 | 2

42 | High-performance liquid chromatography 1260, , Agilent | Purge Valve Long With PTFE Frit | 4

43 | High-performance liquid chromatography 1260, , Agilent | Capillary Outlet ball valve to piston 2 | 1

44 | High-performance liquid chromatography 1260, , Agilent | SST connecting capillary,60cm, 0.17mm | 1

45 | High-performance liquid chromatography 1260, , Agilent | Flex Board Kit | 1

46 | High-performance liquid chromatography 1260, , Agilent | Needle, G1313A Autosampler | 6

47 | High-performance liquid chromatography 1260, , Agilent | Capillary, 0.17x90mm 1/16 in male/male | 1

48 | High-performance liquid chromatography 1260, , Agilent | Vacuum Tube, G1322A | 1

49 | High-performance liquid chromatography 1260, , Agilent | Collared Column Nut, Self-Tightening MSD | 2

50 | High-performance liquid chromatography 1260, , Agilent | Tubing kit degasses to pump | 1

51 | High-performance liquid chromatography 1260, , Agilent | Seat assy 0.17mm ID Standard Autosampler | 5

52 | High-performance liquid chromatography 1260, , Agilent | SST capillary 90µm, / 90cm, 0.17mm id, 1/16 fit / ftil | 1

53 | High-performance liquid chromatography 1260, , Agilent | 100 uL analytical head assembly | 1

54 | High-performance liquid chromatography 1290, , Agilent | Loop Capillary Waste Tube | 1

55 | High-performance liquid chromatography 1260, , Agilent | Low Carry Over Seat 0.12 | 2

56 | High-performance liquid chromatography 1260, , Agilent | Needle Assy for G1367D | 3

57 | High-performance liquid chromatography 1260, , Agilent | Seal support back up assy for G1367D | 1

58 | High-performance liquid chromatography 1290, , Agilent | Support ring integrated for 1290 pump | 2

59 | High-performance liquid chromatography 1290, , Agilent | Inlet Valve | 1

60 | High-performance liquid chromatography 1290, , Agilent | Outlet Valve 1290 Infinity pump | 1

61 | High-performance liquid chromatography 1290, , Agilent | Loop assembly | 1

62 | High-performance liquid chromatography 1290, , Agilent | Seat assembly 0.12mm 1290 Infinity LC | 2

63 | High-performance liquid chromatography 1290, , Agilent | Needle Assembly | 2

64 | Gas Chromatography 7890, Agilent | Big Universal Trap, 1/8inch fttgs,Helium | 4

65 | Gas Chromatography 7890, Agilent | Big Universal Trap, 1/8i fttgs, Nitrogen | 4

66 | Gas Chromatography 7890, Agilent | Filament,high temperature EI for GCMS | 3

67 | Gas Chromatography 7890, Agilent | Agilent Vacuum Fluid 45 Platinum, 1Qt | 3

68 | Gas Chromatography 7890, Agilent | Ferrule, 0.4mm VG 0.1-0.25 col 10/PK | 2

69 | Gas Chromatography 7890, Agilent | Ferrule, 0.4mm VG cond .25 col lng 10/PK | 2

70 | Gas Chromatography 7890, Agilent | Gold Plated Inlet Seal and Washer, 10/pk | 4

71 | Gas Chromatography 7890, Agilent | FID Jet, universal fit, 0.011 inch ID | 2

72 | Gas Chromatography 7890, Agilent | Ignitor Glow Plug Assembly | 1

73 | Gas Chromatography 7890, Agilent | Liner, Ul, universal, low / Liner,UI,universal,low prss drop, GW, 5/pk / drop,GW,5/pk | 2

74 | Gas Chromatography 7890, Agilent | Gas Clean Filter FID Kit 1/4 in | 2

75 | Nitrogen Generator-Peak N300DR Generator | Membrane Dryer Part | 2

76 | Nitrogen Generator-Peak N300DR Generator | Screw pozi pan Part nb: 00-3008 | 1

77 | Nitrogen Generator-Peak N300DR Generator | Screw pozi pan M4x60mm Part nb 00-4432 | 1

78 | Nitrogen Generator-Peak N300DR Generator | Elbow 1/4"M BSPPx6mm push fit Part nb: 02-4603 | 3

79 | Nitrogen Generator-Peak N300DR Generator | Solenoide Valve MAC 3/2 240V Part nb: 02-5440 | 2

80 | Nitrogen Generator-Peak N300DR Generator | Beko Float Drain Part nb: 02-5438 | 2

81 | Nitrogen Generator-Peak N300DR Generator | Beko Element Part nb: 02-5437 | 2

82 | Nitrogen Generator-Genius 3010 Generator | Genius 3010 (GAST) Annual maint kit Part nb: 08-9428 | 1

83 | Nitrogen Generator-Genius 3010 Generator | Compressor for G3010 Part nb: 08-8316 | 1

Part B- Laboratory Machines

Machine | Specification | QTY

High-Pressure liquid Chromatograph System / … | Minimum one year warranty … / | High-Pressure Liquid Chromatograph System | Solvent Rack: - System should have at least 4 vacuum degasser channels solvent rack. - Should accommodate flow rate per channel of 0.001-5ml/min / 0.001-5mL/min or better. - Solvent bottle capacity: Minimum of four 2.5L reservoirs (should be able to also accommodate 5L, 1L, and 0.5L reservoirs sizes). | 1 | Temperature Controlled Column Compartment: - Wide temperature range: 10-85°C or better for reliable separations at elevated, ambient, and sub-ambient / sub ambient temperatures. - Automatic column switching valves for at least 2 columns up to 4 columns - Should accommodate at least 4 columns up to 30 cm in length. - Homogeneous temperature distribution (forced-air or similar efficient technology). - Preferably equipped with sensors for humidity and organic vapors. - Temperature accuracy: ± 0.5 °C - Temperature stability: ±0.15 °C - / ±0.1°C Temperature precision: 0.05 °C - Heat-up/Cool-down Time: : 5 min from ambient to 40 °C 10 min from 40 °C to 20 °C | | DAD Detector: - Wavelength range: 2 (190-950 / ≥ (190-650 nm), - Wavelength bunching 1- 400 nm programmable in steps of 1 nm - Wavelength accuracy: ±1 nm - Light sources: deuterium an Tungsten lamps - Full UV-Vis spectra data acquisition - Built-in holmium oxide filter for wavelength verification. - Diode width <1nm - / ≤1nm Should have lamp identification and life span monitoring. - Should have easy access to cells and lamps for maintenance | | Autosampler: - Sample capacity: 132 x 2 ml vials or better, or up to 36 vials (6 ml) - / mL). Precision: <0.25% RSD from 5µL to 100µL or better - Sample viscosity range: 0.2- 5 cP or better. - Sample carry-over: 0.004% - Injection range: 0.1 – 100 µL in 0.1 µL increments with 100 µl / µL up to 60 MPa, 0.1-900 µl / µL in 0.1 µl / µL increments with 900 µl / µL up to 40 MPa | | PC and Software: - Latest configuration branded PC. - Minimum of 22" LED monitor. - Must include a LaserJet printer - Minimum operating system: Windows 10 64 bits - Memory: 8GB (1x8GB) DDR4 or better - Storage: 500GB SSD or more advanced - Must have an integrated retention time locking module for analyzing target compounds in complex matrices. - The software module must provide the creation of custom compound databases as well as the utilization of vendor-provided / vendor provided databases. - Must have a unified software platform for data acquisition and data analysis. - Data format must be compatible to advanced statistical package. - 2 copies of offline analysis software - Equipment control and analysis software and license should be included with the system for possible re-installation | 1

Part A-Laboratory Equipment

Items / Item | Specifications | Unit | Quantity

Certified micropipette+ adaptable tips | Volume: 10-100microliter(µL) Channels: Single channel Variable or fixed volume: Variable Calibration certificate with uncertainty calculation, | Pcs | 4

Certified micropipette+ adaptable tips | Volume: 100-1000microliter(µL) Channels: Single channel Variable or fixed volume: Variable Calibration certificate with uncertainty calculation, | Pcs | 4

Certified micropipette+ adaptable tips | Volume: 20-200microliter(µL) Channels: Single channel Variable or fixed volume: Variable Calibration certificate with uncertainty calculation, | Pcs | 2

Certified micropipette+ adaptable t ps / tips | Volume: 5-50microliter(uL) / 5-50microliter(µL) Channels: Single channel Variable or fixed volume: Variable Calibration certificate with uncertainty calculation. | Pcs | 1 / 2

PE Plastic Disposable dropper | Disposable Plastic Dropper with clear scale. Capacity 5 mL, 100pcs per pack, ethylene oxide in a single package. | Pack | 10

Spatula | Length 125 mm, width of flat end: 15 mm, width of spoon: 23 mm, spoon capacity: 2.5 ml (10 pcs/pack) | Pack | 1

Spatula | Length 300 mm, width of flat end: 20 mm, width of spoon: 23 mm, spoon capacity: 2.5 ml (10 pcs/pack) | Pack | 1

Micro spoon Spatula | Stainless steel. One end having a flat spatula and the other end having a micro spoon. 18/10 steel Length: 180mm or 185 mm Spoon (L x W): 9 x 5mm | Pcs | 20

Electronic Pipette Controller | For 0.1-200ml plastic or glass pipettes 8 hours continuous use 2-3-hour charge to full charge Replaceable hydrophobic 0.45µm PTFE filter and safety check valve | Pcs | 2

Electronic Pipette Controller Batteries | Cadmium free / Free environment friendly NiMH battery | Pcs | 2

Weighing boats | Made of borosilicate glass, 3 ml capacity | Pcs | 5

Weighing boats | Made of borosilicate glass, 6 ml capacity | Pcs | 5

Vials | glass vials, clear with screw top, 2 ml / mL capacity, 100pcs/pack | Pack | 10

Screw Caps for vials | sample vial cap PTFE/Silicone septa, Screwable, 100 pcs/pack | Pack | 10

Magnetic Stir Bars | Chemically resistant PTFE coating, Autoclavable Small size: Length*diameter (8*1.5) mm White colour, at least 6 pcs /pack | Pack | 1

Micro Magnetic Stir Bars | Chemically resistant PTFE coating, Autoclavable Small size: Length*diameter (5*2) mm White colour, at least 6 pcs /pack | Pack | 1

Magnetic Stir Bars | Chemically resistant PTFE coating, Autoclavab e / Autoclavable Cylinder shape, Size: Length*diameter (38.1*5) mm White colour, at least 6 pcs /pack | Pack | 1

Magnetic Stir Bars | Chemically resistant PTFE coating, Autoclavable Cylinder shape, Size: Length*diameter (50.8*5) mm White colour, at least 6 pcs /pack | Pack | 1

Buffer solution | standard calibration buffer, pH accuracy at 25ºC ±0.01 / 25°C±0.01 pH, pH value at 25ºC~ / 25°C~ 7.01, 20 mL*25 sachets /package, supolled / supplied with certificate of analysis | Package | 10

Buffer solution | standard calibration buffer, pH accuracy at 25ºC / 25°C ±0.002 pH, pH value at 25ºC~ / 25°C~ 4.01, 20 mL*25 sachets /package, supplied with certificate of analysis | Package | 10

Buffer solution | standarc / standard calibration buffer, pH accuracy at 25ºC / 25°C ±0.01 pH, pH value at 25ºC~ / 25°C~ 10.01, 20 mL*25 sachets /package, supplied with certificate of analysis | Package | 10

General Purpose Cleaning Solution | Specially formulated for cleaning electrodes, 20 mL*25 sachets /package | Package | 10

Electrolyte fill solution | contains 3.5M KCl + AgCl, 500 mL bottle | Bottle | 1

Set of Buffer solutions | Standard calibration buffers, pH accuracy at 25RC / 25°C ±0.01 pH, pH value at 25ºC~ / 25°C~ 4.01, 7 01 and 10.01, set of 3 bottles, 500mL each, supplied with certificate of analysis | Pack | 2

Digital Glass Body pH Electrode for General Purpose | Reference cell type: double, Junction type/flow rate: ceramic, single/15-20 µl/h, / µL/h, body material: glass, tip shape: spheric, Max pressure: 0.1 bar, Temperature range: /5-100ºC, / -5-100°C, Body length/overall length approximately: 120mm/ 175.5mm, with temperature senser, / sensor, outer diameter: 12mm, cable: 1m | Pcs | 1

Analytical balance | Maximum capacity: 250g, Readability: 0.0001g, Minimum weight: 0.01 g, Repeatability: ±0.0002g, Linearity: 0.0003 / Linearity:0.0003 g | Pcs | 1

Container | Stainless steel, up to 6 L for Vertical cutter/blender / cutter/ blender Restesch GM300 SN: 1222090225F | PCS | 3

ve distribution in the cavity.

… / | 1 umables and remote control of the

… / |

Microwave Digestion System

| Minimum one year warranty

| One system that should be able to perform both: microwave digestion and extraction experiments

| -Microwave cavity should feature a 316 stainless steel housing with multi-layers of corrosion resistant coating

| -Should have a large internal cavity: minimum 70 Liters

-Chassis should / | -Chassisshould be protected against acids and solvents with polymer coating

| -Door should be completely made of stainless steel

| -Must have a self-resealing pressure responsive door

| -Multiple independent safety interlocks to prevent microwave emission in case of improper closure or misalignment

| -Exhaust System should / Systemshould be built-in, it should be separated from electronics to prevent corrosion

| -Should have a built-in viewing feature for ultimate visibility to the internal cavity

| -Microwave Emission should be preferably based on a dual magnetron system with rotating diffuser for homogeneous microwa

| -Microwave power should be not less than 1900 Watt

| -Should feature a continuous and PID-controlled microwave emission at all power levels

| -Should meet at least the following Emission and Safety Norms:

| oEN61010-1:2001; EN61010-2-010:2003; UL61010-1:2004

| oCAN/CSA-C22.2 No 61010-2-010:2004

| oIEC 61010-2-010:2003; EN61326-1:2006

| -Standard methods compliance should meet, at least, the following:

| oUS EPA3052; / EPA 3052; US EPA 3051A; US EPA 3546

| oASTM D4309-96; ASTM D-5765; ASTM D-6010; RoHS, WEEE and ELV

| -Should be provided with a large Control terminal with touch screen

| -Should feature a web-based application for external devices, including application library, tutorial videos, spare parts and cons

| system

| -Should be provided with a 15 segments digestion high pressure rotor, or bigger, fully loaded:

| oVessel volume: 100 ml; / mL, maximum temperature: 300'C; / 300°C, Pressure 100 Bar

| oShould include a direct contactless temp control in all vessels A29
